| CVD coated cemented carbide | ||
|---|---|---|
| Grade | Description | Equivalent to ISO |
| YC1015 | MT-CVD coated, the substrate with excellent wear resistance in combination with MT-TiCN, fine grained AL2O3TiN multi-layer coating, which is suitable for finishing of steel. | P05-P15 |
| YC1025 | MT-CVD coated, Cutting edge with good toughness in combination with TiCN+Al2O3(thick)+TiN multi-layer coating, which is suitable for semi-finishing of steel. | P10~P25 |
| YC1035 | MT-CVD coated, the substrate with excellent toughness and plastic deformation resistance in combination with TiCN+Al2O3(thick)+TiN multi-layer coating, which is suitable for roughness of steel. | P20-P35 |
| YC1125 | Special strength toughness of the insert substrates, perfect combinations with MT-TiCN, ultra fine AL2O3 coatings, common grade for steel, suitable for steel, cast iron, stainless steel in semi-finishing, finishing. | P10~P25 |
| YC1315 | The combination of high wear-resistant substrate with MT-TiCN, fine grained Al2O3 and TiN coatings, is an ideal grade of finishing processing of steel, stainless steel in the case of high speed cutting. | P10~P25 |
| YC1325 | With optimized toughness and hardness of the substrate and MT-TiN, fine grain Al2O3 and TiN coating and with a special post-treatment process, the formation of excellent performance of the double-color coating, suitable for steel, stainless steel and cast iron in semi-finishing and finishing. | P10~P25 |
| YC1335 | Substrate with high strength and strong resistance to plastic deformation combined with MT-TiCN, fine grained Al2O3 and TiN coating having great toughness, is suitable for light load roughing of steel, stainless steel and cast iron. | P10~P25 |
| YC2105 | MT-CVD coated, the super fine grain size substrate with excellent hardness in combination with Al2O3(extra thick) coating, the smooth surface, which is suitable for turning and milling of grey cast iron at high speed. | K05-K15 |
| YC2115 | MT-CVD coated, the substrate with excellent hardness and stripping resistance in combination with Al2O3(thick) coating, the smooth surface of the tools, which is suitable for turning and milling of cast iron at middle and high speed. | K10-K30 |
| YC2215 | High wear-resistant substrate, new generation coating process with perfect combination of MT-Ti(CN), Super Al2O3, TiCN coating, initial grades of ductile cast iron, forged cast iron, high cutting speed allowance. | K10~K30 |
| PVD coated cemented carbide | ||
|---|---|---|
| Grade | Description | Equivalent to ISO |
| YP3025 | 2-4um TiAlN PVD coated, combining with ultra-fine particles' substrates with high-toughness, suitable for all materials, stainless steel, steel, cast alloy in finishing, semi-finishing. | P10-P25 K15-K30 |
| YP3125 | 2-4um AlCr+AlCrSiN PVD coated, combining with ultra-fine particles' substrates with high-toughness, suitable for all materials, stainless steel, steel, cast alloy in finishing, semi-finishing. | P10-P25 K15-K30 M10-M25 |
| YP3225 | 2-4um AlCr+AlCrSiN PVD coating, combined with ultra-fine particle matrix, has high wear resistance, suitable for finishing and semi-finishing of heat-treated steel, stainless steel and quenched steel. | P10-P25 K15-K30 M10-M25 |
| YP3330 | The latest AlCr+AlCrSiN PVD coatings, combined with ultra-fine particle substrates, has high wear resistance and excellent performance in finishing and semi-finishing of stainless and hardened steel. | P10-P25 K15-K30 M10-M25 |
| YR3025 | 2-4um TiAlN+TiN PVD coated, combining with fine particles' substrates with high-toughness, suitable for all materials, high-temperature alloy Ti alloy in semi-finishing, roughing. | P20-P30 K20-K35 |
| YR3025 (S10-S25) | Unique material matrix, with 2-4um TiAlN PVD coating, with high toughness and heat resistance, suitable for high temperature alloy, heat resistant alloy and other difficult to process materials finishing, semi-finishing. | S10-S25 |
| YR3325 | The latest AlCr+AlCrSiN PVD coatings, combined with unique rare metal substrates, offer high wear resistance and excellent performance in finishing and semi-finishing of superalloys and heat resistant alloys. | S10-S25 |
