Advanced Siemens System CNC Lathe Featuring Taiwan Syntec Control System

After-sales Service:	Troubleshooting & Tech Support
Warranty:	1 Year
Application:	Metal

Basic Info.

Model NO. NC-115/1000

Process Usage Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools

Movement Method Point to Point Control

Control Method Semi-Closed Loop Control

Numerical Control CNC/MNC

Processing Precision 0.01~0.02(mm)

Performance Classification High-End CNC Machine Tools

Certification CE, ISO 9001

Condition New

Noq 1

Delivery Time 30days

Motor Taiwan Syntec Control System

Applications Automotive, Aerospace, and Manufacturing

Transport Package Shipping in Wooden Cases

Specification 3580× 2150× 1950mm

Production Capacity 1000-2000

Packaging & Delivery

Package Size 3580.00cm * 2150.00cm * 1950.00cm

Package Gross Weight 6600.000kg

Product Description

Advanced Siemens System CNC Lathe Featuring Taiwan Syntec Control System

The NC-115/1000 CNC lathe is a marvel of precision engineering, featuring the highly-regarded Japanese FANUC0i-TF control system. This cutting-edge lathe is crafted in strict adherence to ISO standards for turning machining centers, ensuring unparalleled static accuracy and dimensional precision. Its robust and durable inclined bed structure is complemented by performance-enhancing reverse finite element analysis in its structural and casting designs. Proudly engineered, this CNC lathe delivers superior machining results, making it an indispensable asset to professionals in the CNC machining industry. Its versatility across various applications further underscores its reliability and excellence.

The NC-115/1000 boasts a sophisticated chuck-type spindle with the nose model ANSIA2-11, accommodating an impressive 18.0" (380mm) three-jaw power chuck. This standard configuration includes a set of soft jaws, ensuring secure and precise workpiece handling. The spindle's advanced non-contact magnetic induction encoder facilitates complex functions such as rigid tapping, 1-degree indexing, and meticulous spindle positioning, enhancing the machine's precision and operational capabilities.

Featuring an ultra-thin hydraulic clamping mechanism integrated with a coolant circuit system, this machine tool maintains versatility and efficiency by accommodating either a three-jaw power chuck or a chuck adapter. The adoption of ultra-thin rotary cylinders reduces the machine's footprint while maintaining operational efficiency. A conveniently placed hydraulic rotary cylinder pressure gauge on the machine's front end allows for real-time monitoring of the chuck's grip strength. The brushless servo motor ensures swift and precise turret rotation, with a three-piece end gear disk providing secure locking. Tool changes are exceptionally fast, with adjacent position changes taking only 0.18 seconds and maximum repositioning completed in 1.0 second. The tool turret's repeat positioning accuracy is a remarkable 2.5 arcseconds, reflecting its precision engineering.

NC-115/1000 Parameter Specification

Category	Item	Specification
Spindle Specifications	Spindle Nose Type	ANSI A2-11
	Spindle Bore Diameter	130mm
	three-jaw chuck holding capability	18inch/380mm
	Spindle Center Height	1050mm
	Spindle Center to Front Door Distance	410mm
	Drawbar Actuation	Hydraulic
FANUC 0i-TF/Plus Control System	Spindle Motor Power	22kW (continuous) / 27.5kW (15-min duty)
	Base Spindle Speed	1000rpm
	Max Spindle Speed	1500rpm
	Spindle Torque Output	285Nm/15min
	X-axis Servo Motor Power	2.4kw
	Z-axis Servo Motor Power	2.4kw
Machining Capacity	Max Swing Over Bed	750mm
	Max Workpiece Length	1050mm
	Max Workpiece Diameter	500mm
	Max Bar Capacity Through Spindle	120mm
X/Z Axis Movement	Max Travel	-
	X-axis	350mm (with SD-160/8025 Turret)
	Z-axis	1060mm
	Rapid Traverse Speed (X/Z)	20m/min
Turret Specifications	Drive Type	Servo Motor
	Number of Tools	12
	Square Tool Holder Size	25×25mm
	Round Tool Holder Size	50mm
	Tool-to-Tool Indexing Time	0.18seconds
Tailstock (Optional)	Tailstock Travel	700mm
	Max Supported Workpiece Length	960mm
	Min Supported Workpiece Length	200mm
Chip Management	Coolant Tank Capacity	125L
Chip Management	Coolant Pressure	1.2BAR
Machine Dimensions & Weight	With Right-Side Chip Conveyor	3580×2150× 1950mm (excluding chip conveyor) 4800X2150X1950mm (including the right side chip conveyor)
Machine Dimensions & Weight	Weight	6600kg
Optional Configurations
Spindle Chuck	-	Diameter of the through hole
Extendable material receiver	Max Workpiece Diameter	52mm
Extendable material receiver	Max Workpiece Length	110mm
Swing arm type material receiver	Max Workpiece Diameter	52mm
Swing arm type material receiver	Max Workpiece Length	150mm
Workpiece Conveyor System
Chip Removal System	Chain Type	Suitable for long/curled chips
Chip Removal System	Scraper Type	Ideal for fine/discontinuous chips
Tool Measurement Device	Fully automatic or manual operation	-
Workpiece Measurement Device	-	-
Automatic Centralized Lubrication System	-	-
Mist Collector	0.5 HP motor	-
Bar Feeder (Bar Length Options)	-	1250mm
Bar Feeder (Bar Length Options)	-	3200mm
High-Pressure Through-Tool Coolant	Coolant tank capacity	200L
High-Pressure Through-Tool Coolant	Coolant pressure	20BAR

Main Products

Company Profile

Certifications

Exhibition & Our Customers

Packaging & Shipping

FAQ

Q How can I choose the most suitable machines?

Please tell us your specifications, and we will help you select the best model, or you can choose the exact model yourself. Alternatively, you can send us the product drawings, and we will recommend the most suitable machines for your needs.

Q What are the main products available?

We specialize in all kinds of machines, such as CNC Lathe Machine, CNC Milling Machine, CNC Turning Machine, Vertical Machining Center, Horizontal Machining Center, Lathe Machines, and turning & milling composite processing machinery.

Q What control system is used in the NC-115/1000 CNC lathe?

The machine is equipped with the highly-regarded Japanese FANUC 0i-TF control system as standard for optimal performance and reliability.

Q What are the spindle configurations and clamping capabilities?

It features an ANSI A2-11 spindle nose, a 130mm spindle bore diameter, and accommodates an 18-inch (380mm) three-jaw power chuck with a standard set of soft jaws.

Q How fast are the tool changes on the turret?

Driven by a brushless servo motor, the turret performs exceptionally fast tool changes, taking only 0.18 seconds for adjacent positions and a maximum of 1.0 second for a full repositioning.

Q What are the physical dimensions and weight of the machine?

The standard dimensions are 3580×2150×1950mm (excluding the chip conveyor) and 4800×2150×1950mm with the right-side chip conveyor. The overall weight is approximately 6600kg.
